C7769-60169 Rollfeed Cutter Bushing HP DesignJet 500 / 510 / 800 / T1200

Genuine OEM New C7769-60169 Cutter Bushing for HP DesignJet 500 DesignJet 510 DesignJet 800 DesignJet T1200 Series plotter.
Bushing is installed in the end of the Cutter Assembly to move along the slider rod.  When the bushing is worn it can allow the cutter to twist while in motion.
Cutter is implicated as the cause of system error code 31:XX

used in these HP DesignJet plotter Models
DesignJet 500 (24-inch)  C7769B,  C7769BR
DesignJet 500PS (24-inch/Postscript)  C7769C,  C7769CR
DesignJet 500 (42-inch)  C7770B,  C7770BR
DesignJet 500PS (42-inch/Postscript)  C7770C,  C7770CR
Designjet 510 24-in Printer
Designjet 510ps 24-in Printer
Designjet 510 42-in Printer
Designjet 510ps 42-in Printer
DesignJet 800 (24-inch)  C7779B,  C7779BR
DesignJet 800PS (24-inch/Postscript)  C7779C,  C7779CR
DesignJet 800 (42-inch)  C7780B,  C7780BR
DesignJet 800PS (42-inch/Postscript)  C7780C,  C7780CR
DesignJet Copier CC800PS  Q1262A
DesignJet 815 MFP  Q1279A,  Q1279AR
DESIGNJET T1200 44IN PRINTER CH538A, CH538AR
DESIGNJET T1200 44IN PS PRINTER CK834A, CK834AR

Refer to page 8-32 in the service manual for removal and replacement instructions.

New OEM HP Part Requires NO Exchange of Old Part.

C7769-60169, oem cartridge bushing,
